安装形式 | 非埋入式 | 工作电压 | 直流型：10-30VDC |
检测距离 | 15mm±20% | 静态电流 | DC三线型≤2.5mA |
设定距离 | 0~12mm | 响应频率 | 30Hz |
回差值 | 小于检测距离的10% | 电流输出 | 300mA |
标准检测体 | 45×45×1铁 | 防护等级 | IP66（IEC规格） |
残留电压 | DC三线式：≤1.5VDC，DC二线式：≤4VDC，AC二线式：≤8VAC | ||
温度影响 | 在-25℃到+70℃范围内，对在+25℃时的检测距离是在10%以下 | ||
绝缘电阻 | ≥50MΩ Min （500VDC Mega基准） | ||
耐压 | 1500VAC 50/60Hz 一分钟 | ||
抗振动 | 抗振动：10-55Hz（周期每分钟）复振幅1mm，X、Y、Z各方向2小时 | ||
抗冲击 | 抗冲击：500M/S2( 50G ) X、Y、Z各方向3次 | ||
环境温度 | 工作时 : -30 to +80℃(未结冰状态下) | ||
储存时 : -30 to +80℃未结冰状态下 ) | |||
环境湿度 | 工作时: 35 to 95% RH | ||
指示灯 | 动作显示（红色LED） | ||
克特接近开关是一种无需与运动部件进行机械直接接触而可以作的位置开关，当物体接近开关的感应面到动作距离时，不需要机械接触及施加任何压力即可使开关动作，从而驱动直流电器或给计算机（plc)装置提供控制指令。接近开关是种开关型传感器（即无触点开关），它既有行程开关、微动开关的特性，同时具有传感性能，且动作可靠，性能稳定，频率响应快，应用寿命长，抗干扰能力强等、并具有防水、防震、耐腐蚀等特点。产品有电感式、电容式、霍尔式、交、直流型。
克特接近开关又称无触点接近开关，是理想的电子开关量传感器。当金属检测体接近开关的感应区域，开关就能无接触，无压力、无火花、迅速发出电气指令，准确反应出运动机构的位置和行程，即使用于一般的行程控制，其定位精度、作频率、使用寿命、安装调整的方便性和对恶劣环境的适用能力，是一般机械式行程开关所不能相比的。它广泛地应用于机床、冶金、化工、轻纺和印刷等行业。在自动控制系统中可作为限位、计数、定位控制和自动保护环节等。
KTGEE proximity switch is a type of position switch that can be used without direct mechanical contact with moving parts. When an object approaches the sensing surface of the switch to the action distance, no mechanical contact or pressure is required to activate the switch, thereby driving DC electrical appliances or providing control instructions to computer (PLC) devices. A proximity switch is a switch type sensor (i.e. a contactless switch) that combines the characteristics of a travel switch and a micro switch, as well as sensing performance. It has reliable action, stable performance, fast frequency response, long application life, strong anti-interference ability, and is waterproof, shockproof, and corrosion-resistant. The products include inductive, capacitive, Hall, AC, and DC types.
KTGEE proximity switch, also known as contactless proximity switch, is an ideal electronic switch quantity sensor. When the metal detector approaches the sensing area of the switch, the switch can quickly issue electrical commands without contact, pressure, or sparks, accurately reflecting the position and stroke of the moving mechanism. Even for general stroke control, its positioning accuracy, operating frequency, service life, ease of installation and adjustment, and adaptability to harsh environments cannot be compared to general mechanical stroke switches. It is widely used in industries such as machine tools, metallurgy, chemical engineering, textiles, and printing. In automatic control systems, it can be used as a limiting, counting, positioning control, and automatic protection link.
